Brand Name : Deyuan
Model Number : DY0201023
Certification : CCS,ABS,DNV,BV,RINA ..
Place of Origin : China
MOQ : 1 set
Price : Negotiable
Payment Terms : L/C, T/T, Western Union
Supply Ability : 20 sets/month
Delivery Time : Within 20 to 30 days, According to customers's order
Packaging Details : Export packing
Type : Diesel Engine Driven Rudder Propeller
Blade : 3-5pcs
Input power Max. : 45KW
Input torque Max. : 200N.m
Material : Cu1.Cu3,Copper,bronze
Propeller Dia.Max. : 500mm
200N Electric Boat Propulsion Systems , Rudder Propeller Marine Propulsion Engine
Product Feature:
1. Material:Cu1.Cu3,Copper,bronze.
2. Certificate:ABS,BV,CCS,DNV GL, KR, LR, NK.
3. Blades:3-5pcs.
Specification:
China Deyuan Marine Fitting Co.,ltd is leading supplier of Tunnel thruster,Marine rudder propeller,marine
controllable pitch propeller,6 blades marine propeller,79600DWT Bulk Ship Fixed Pitch propeller,fixed
pitched marine propeller,oil cylinder of adjustable propeller,propeller hub,Pls contact us for more
specific details.
We can design and make propellers for container ships,Cargo ships,tankers, and kinds of boats.
The material can be : Cu1.Cu3,Copper,bronze.
The dimension can be according to your requirements.
We are able to make Max 10m diatermeter propeller.
The blades can be 3.4.5.
The certificate of ABS,BV,CCS,DNV GL, KR, LR, NK and etc are availabe.
Type | Input power Max.(KW) | Input speed rated.(rpm) | Input torque max.(N.m) | Propeller Dia.max. (mm) | Reduction ratio | Weight(kg) |
SRP12 | 45 | 2300 | 200 | 500 | 1.93 | 65 |
SRP45 | 100 | 2500 | 450 | 800 | 2.5 | 190 |
SRP85 | 210 | 2350 | 850 | 950 | 2.68 | 400 |
SRP138 | 260 | 2000 | 1380 | 1100 | 3.01 | 1200 |
SRP180A | 340 | 1800 | 1800 | 1150 | 3.46 | 1450 |
SRP180B | 280 | 1500 | 1800 | 1150 | 2.88 | 1450 |
SRP180C | 180 | 1000 | 1800 | 1150 | 2.526 | 1450 |
SRP226 | 350 | 1800 | 2260 | 1350 | 3.34 | 2000 |
SRP280 | 480 | 1800 | 2800 | 1350 | 3.96 | 2100 |
SRP310A | 580 | 1800 | 3070 | 1550 | 3.718 | 2500 |
![]() |
200N Electric Boat Propulsion Systems , Rudder Propeller Marine Propulsion Engine Images |
